Thông số kỹ thuật:
| Algorithms and Technologies | 1DMax, 2DMax, Hotbars, PowerGrid |
| Image Sensor | 1/3 inch CMOS |
| Image Sensor Properties | Diagonal 6.21 mm, 3.45 μm square pixels |
| Image Resolution | 1440 x 1080 pixels (1.6 MP) |
| Weight | 6.2 mm assembly: 99 g | 16 mm assembly: 132 g |
| Power | USB powered: USB BC 1.2 port, USB 3.0 port with 4.5 W or higher, USB-C with USB-PD (5 V/3 A) External power supply: +5 – +24 V DC. Supplied by limited-energy circuit according to IEC/ UL/ CSA 61010-1 |
| Power comsumption | Average: 3.3 W | Maximum: 4.2 W |
| Light | Red Standard |
| Lens | 6.2 mm HSLL clear |
| Operating Temperature | 0-40° C (32–104° F) |
| Storage Temperature | -10–60° C (14–140° F) |
| Humidity | <95% non-condensing |
| Environment | DataMan 80: IP67+B2 |
| . | DataMan 80 with Sound Amplifier: IP44 Altitude: 2000 m, indoor use only, pollution degree II |
| Shock | IEC 60068-2-27 – 500 shocks in each polarity of each (X, Y, and Z) axis, 3000 shocks total, semi-sinusoidal,11 g, 10 ms |
| Shock (Shipping and storage) | ISTA-1A Standardized Testing – Packaged Products 150 lb or less |
| Vibration | IEC 60068-2-6: vibration test in each of the three main axis for 2 hours @ 10Gs (10 to 500 Hz at 100m/s2/15 mm) |
| Vibration (shipping and storage) | FedEx Vibration Testing for packaged products 150 lbs or less |
| Code | 1D barcodes: Codabar, Code 39, Code 128, Code 93, Code 25, Interleaved 2 of 5, Postal Codes, UPC/EAN/JAN, MSI 2D barcodes: Data Matrix (IDMax and IDQuick: ECC 0, 50, 80, 100, 140, and 200), QR Code, microQR, PDF 417, AztecCode, DotCode, MaxiCode |
| High speed output 0 | I MAX : 50 mA ; V OL: ≤ ±3 V @ 50 mA |
| Input 0 | VIL: :5 ± 6 V; VIH: ±12V; ITYP : 4.2 mA @ 24 V |
